Honda HRN216VYA User Manual

9-8
IGNITION COIL/FLYWHEEL HRN216
2. FLYWHEEL
DISASSEMBLY/REASSEMBLY
1. Remove the fan cover (P. 7 -3 ).
2. Remove the ignition coil (P. 9 - 2
).
3. Remove the electric starter (VLA type only) (P. 9 -1 2
).
PKA/VKA/VLA types: 55 N•m (41 ft-lb)
VYA type: 75 N•m (55 ft-lb)
FLYWHEEL NUT (14 mm)
INSTALLATION:
When installing the flywheel, check
to be sure that the woodruff key
remains in its slot in the crankshaft.
FLYWHEEL
WOODRUFF KEY

Honda HRN216VYA Specifications

General

Engine	Honda GCV170
Cutting Width	21 inches
Deck Material	Steel
Starting System	Recoil
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
Cutting Height Adjustment	6 positions
Drive System	Variable Speed
