Honda HRN216VYA User Manual

13-4
TRANSMISSION/DRIVE BELT HRN216
VYA TYPE
REMOVAL
1. Drain the fuel tank (P. 3 -11
) and engine oil (P. 3 - 6 ).
2. Disconnect the spark plug cap (P. 3 -8
).
3. Fully loosen the Smart Drive cable adjuster.
4. Remove the blades. Use a pair of thick leather gloves to
hold the blades with your hand to prevent the blades
from turning, and then remove the two blade bolts and
special washers.
JAM NUT
LOOSEN
TIGHTEN
ADJUSTER
MARK
UPPER BLADE
LOWER
BLADE
SPECIAL
WASHER (2)
BLADE BOLT (2)

Honda HRN216VYA Specifications

General

Engine	Honda GCV170
Cutting Width	21 inches
Deck Material	Steel
Starting System	Recoil
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
Cutting Height Adjustment	6 positions
Drive System	Variable Speed
