7-3
HRN216 RECOIL STARTER
3. FAN COVER REMOVAL/INSTALLATION
Remove the top cover (P. 7 -1 ), and then reinstall the fuel tank cap to prevent dirt or debris from entering the fuel tank.
The recoil starter assembly does not need to be removed to remove the fan cover.
Reassembly is the reverse order of removal.
FAN COVER
6 x 23 mm BOLT* (5)
* CT type (cutting threads)

Honda HRN216VYA Specifications

General

Engine	Honda GCV170
Cutting Width	21 inches
Deck Material	Steel
Starting System	Recoil
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
Cutting Height Adjustment	6 positions
Drive System	Variable Speed
