Fire Alarm Control Panel IQ8Control C/M
FB 798951.GB0 / 01.09 45
4.3.6 Technical data Basic module
Operating voltage : Internal via the power supply module, +5 V DC / + 12 V DC
Quiescent current : approx 215 mA @ 12 V DC without operating module
approx 230 mA @ 12 V DC incl. operating module
approx 295 mA @ 12 V DC incl. operating module ¼ VGA
Emergency mode operation : available
Fuses : F1 = T1,25A H/230 V AC
F2 = T2,5A
F3 = T2,5A
F4 = T2A / 12 V DC
Î mains voltage, primary
Î battery 1
Î battery 2
Î supply voltage
for external devices
Supply voltage for external devices : max. 12 V DC/ 2A (terminal +Ubext / GND)
Common fault relay : 1 dry change-over contact
Contact rating max. 30 V DC / 1A
Relay operation with common fault programmable in the customer
data
Terminals
- Mains connection
- Communication cables
:
:
1,5mm
2
up to max. 2,5mm
2
removable, max. 1,5mm
2
TTY -interface
or
RS485-1 interface
:
:
20 mA, max. 1000m cable length
max. 1000m cable length
Do not connect relays (AE) of the FACP with alternating voltage. Even in the case of a >dry relay
contact< it is not possible to switch an external AC-voltage.
Compatibility : Part No. 772481
Î Basic module IQ8Control C
Part No. 772482
Î Basic module IQ8Control M
The Basic module is suited for the Fire Alarm Control Panels
IQ8Control C/M with the required power supply module
(Part No. 802426 from index G).
The required loop voltage (27,5 V or 42 V for esserbus
®
PLus)
must be selected on the power supply module.
For the Fire Alarm Control Panel system 8000 the basic module
may be used as replacement device. This requires the power
supply module (Part No. 802426 from index G).
