Honeywell IQ8Control C User Manual

Fire Alarm Control Panel IQ8Control C/M
68 FB 798951.GB0 / 01.09
5.1.3 Technical Data Analog loop module
Part No. 784382 / 784382.10 /
784382.D0 (esserbus
®
)
Part No. 804382 / 804382.10 /
804382.D0 (esserbus
®
PLus)
Internal voltage supply Internal +12 V and +27,5 V Internal +12 V and +42 V
Quiescent current
(with 127 loop devices)
60 mA @ 12 V 60 mA @ 12 V
Emergency operation yes yes
Terminals removable, for max. 1,5 mm
2
wire
gauge
removable, for max. 1,5 mm
2
wire
gauge
Recommended connecting
cable
 Telephone cable I-Y (ST) Y n x 2 x 0.8mm with special designation or
fire detection cable
 Loop resistance 75  @ 1000 m loop length
(measured from terminal A+ to B+)
 Total loop resistance max. 130  (measured from terminal A+ to B+)
 Up to 3500 m total loop length is possible for IQ8 fire detectors or alarm
devices with consideration of the load factor
 The permitted loop length depends on the number and type of the loop devices and may differ
from the max. loop length.
 max. 2 analog loop modules Part No. 804382 / 804382.10 / 804382.D0 per IQ8Control C as well
as max. 4 or 6 modules per IQ8Control M
 Part No. 784382 / 784382.10 / 784382.D0 Î analog loop module (esserbus
®
)
Analog loop module to connect Fire detectors and esserbus
®
-transponder. The required loop
voltage 27.5 V
must be selected via the jumper on the power supply module Part No. 802426 of
the FACP
 Part No. 804382 / 804382.10 / 804382.D0 Î analog loop module (esserbus
®
-PLus)
Analog loop module to connect Fire detectors and esserbus
®
-transponder and alarm devices.
The required loop voltage 42 V
must be selected via the jumper on the power supply module
(Part No. 802426) of the FACP.
Maximum line lengths based on the total load factor of a loop
FACP Loop 2 Loop 3 Loop 4 Loop 5 Loop 6 max. loop lenght Loop 1
up to 700 m 91 to 96 91 to 96 91 to 96 91 to 96 X X
800 m 85 to 90 85 to 90 85 to 90 85 to 90 X X
1000 m 73 to 78 73 to 78 73 to 78 73 to 78 X X
1100 m 67 to 72 67 to 72 67 to 72 67 to 72 X X
1300 m 61 to 66 61 to 66 61 to 66 61 to 66 X X
1500 m 55 to 60 55 to 60 55 to 60 55 to 60 X X
1600 m 49 to 54 49 to 54 49 to 54 49 to 54 X X
2000 m 1 to 48 1 to 48 1 to 48 1 to 48 X X
IQ8Control M
up to 4 loops
up to 3500 m 0 0 0 0 X X
up to 700 m 46 to 48 46 to 48 46 to 48 46 to 48 46 to 48 46 to 48
800 m 40 to 45 40 to 45 40 to 45 40 to 45 40 to 45 40 to 45
1000 m 35 to 39 35 to 39 35 to 39 35 to 39 35 to 39 35 to 39
1100 m 34 to 36 34 to 36 34 to 36 34 to 36 34 to 36 34 to 36
1300 m 31 to 33 31 to 33 31 to 33 31 to 33 31 to 33 31 to 33
1500 m 28 to 30 28 to 30 28 to 30 28 to 30 28 to 30 28 to 30
1600 m 25 to 27 25 to 27 25 to 27 25 to 27 25 to 27 25 to 27
2000 m 1 to 24 1 to 24 1 to 24 1 to 24 1 to 24 1 to 24
IQ8Control M
up to 6 loops
up to 3500 m 0 0 0 0 0 0
