Honeywell IQ8Control C User Manual

Fire Alarm Control Panel IQ8Control C/M
70 FB 798951.GB0 / 01.09
5.2.1 essernet
®
micro module (Part No. 784840 / 784840.10 and 784841 / 784841.10)
The essernet
®
micro module must be placed on the micro module slot of the Basic module. There for it is
required to set the corresponding jumpers on the Basic module to configure the terminals for the essernet
®
micro module.
 essernet

micro module 62,5 kBd (Part No. 784840 / 784840.10)
 essernet

micro module 500 kBd (Part No. 784841 / 784841.10)
S2
LED
essernet
®
module
red
yellow
green
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
X1
S1
X4 X5
Fig. 61: essernet
®
micro module (Part No. 784840 / 784841)
S2
LED
essernet
®
module
red
yellow
green
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
X1
S1
X4 X5
Fig. 62: essernet
®
micro module (Part No. 784840.10 / 784841.10)
