Fire Alarm Control Panel IQ8Control C/M
FB 798951.GB0 / 01.09 57
4.3.10 Technical data Field device module
Operating voltage : Internal via the power supply module, +5 V DC / + 12V DC
Quiescent current : approx. 15 mA @ 12 V DC
Fuse F1
Fuse F2, F3, F4
:
:
T1A – slow blow (relay K1)
T2A - slow blow (relays K2 to K4)
: Max. 1,5 mm
2
wire gauge
, removable terminals
:
Relay for connecting a master box. May also be used as a freely
programmable relay.
Selection of operating mode and emergency function by means of
jumpers.
Contact rating when used as a >non-monitored change-over
contact< contact rating < 30 V DC/ max.1 A.
No dry contact cause of the integrated EMI protection.
Relay K1
:
Relay with common function. May also be used as a freely
programmable relay.
Selection of operating mode and emergency function by means of
jumpers.
Contact rating when used as a >non-monitored change-over
contact<, contact rating < 30 V DC/ max.2A
No dry contact cause of the integrated EMI protection.
Relay K2, K3, K4
Fire department operating panel : 8 digital inputs
8 outputs - max. 12 V DC / 20 mA per output
Internal primary loop :
monitored 10 k
(normal) / 5 k (FIRE) / 1 k (fault)
Application e.g. for essernet
®
-emergency operation
Compatibility : Part No.772479
« Field device module without micro module slot
Part No.772477
« Field device module with micro module slot
The IQ8Control FACP's relays may only be connected to DC voltages. No AC voltage may be
applied, not even when a relay is programmed as a >non-monitored change-over contact<!
