Fire Alarm Control Panel IQ8Control C/M
86 FB 798951.GB0 / 01.09
6.3.2 Technical data interface modules
RS 232/TTY module (Part No. 784842)
Operating voltage : Internal via the power supply module, + 5 V DC / +12 V DC
Quiescent current : TTY-mode approx. 55 mA @ 12 V DC
RS232-mode approx. 35 mA @ 12 V DC
Interface type : TTY (20mA) or RS232
selectable in panels date configuration
Transmission speed : max. 19200 bit/s
Terminals : max. 1,5 mm
2
wire gauge, removable
Interface cable length : TTY
Î max. 1000 m
RS 232
Î max. 15 m
