Fire Alarm Control Panel IQ8Control C/M
FB 798951.GB0 / 01.09 83
6.2.1 Technical Data Relay module
4-relay module (Part No. 787530)
Operating voltage : Internal via the power supply module, + 5 V DC / +12 V DC
Quiescent current : approx. 10 mA @ 12 V DC
Fuse (F1, F2, F3, F4) : Multifuse 1 A (for Relay K1 to K4)
Relay (K1, K2, K3, K4) : 4 programmable contacts - normally Open or normally close
(not monitored)
Contact rating : max. 30 V DC / 1 A per output
Terminals : max. 1,5mm
2
wire gauge, removable
3-relay module
(Part No. 787531)
3-relay common fault module
(Part No. 787532)
Voltage : Internal via the power supply
module, + 5 V DC / +12 V DC
Internal via the power supply module,
+ 5 V DC / +12 V DC
Quiescent current
consumption
: 5 mA@ 12 V DC 15 mA@ 12 V DC
Relay : 3 monitored, normally open or
normally close contacts
2 monitored, normally open or
normally close contacts plus a
common fault relay (energized in
normal operation)
Contact rating : max. 30 V DC / 1 A per output max. 30 V DC / 1 A per output
Fuse : Multifuse 1 A (per relay) Multifuse 1 A (per relay)
Terminals max. 1,5mm
2
wire gauge, removable
Compatibility : The Relay modules may be operated on a free selectable micro module
slot of the FACP IQ8Control.
For System 8000 fire alarm control panels the relay module may be used
as a replacement devices.
Damage to the system!

No AC voltages may be applied to the relays built-into the FACP IQ8Control. This applies also
to those relays operated in the >non-monitored< mode!
 Observe Schematic wiring of inductive loads!
