Honeywell IQ8Control C User Manual

Fire Alarm Control Panel IQ8Control C/M
62 FB 798951.GB0 / 01.09
5 Micro module
The FACP IQ8Control C / M has a modular design, so that micro modules can be replaced/extended at any
time.
Only remove or insert micro modules when the FACP is voltage free.
 Switch off the power and battery supply.
 Wait at least 10 seconds before the micro modules are replaced or supplemented.
 Take suitable measures to discharge static electricity.
 Check correct installation (micro modules and connection cables).
 Switch on the power and battery supply.
 If necessary, check/supplement the customer data using the programming software tools
8000.
5.1 Analog loop modules
The following two analog loop modules are available for the Fire Alarm Control Panel IQ8Control C/M:
esserbus
®
analog loop module (Part No.784382 / 784382.10 / 784382.D0)
To connect fire detectors series 9200 and FACP esserbus
®
transponders. For the analog loop module operation
the power supply module (Part No.802426) must be configured with the appropriate jumper to 27,5V loop
voltage.
esserbus
®
PLus analog loop module (Part No.804382 / 804382.10 / 804382.D0)
Fire Alarm Control Panels IQ8Control C/M with esserbus
®
PLus are based on the standard esserbus
®
functionality with the additional function to connect and power audible alarm devices directly to the analog loop.
For this operation of the analog loop module it is necessary to set the loop voltage of the Power supply module
(Part No.802426) with the appropriate jumper to 42 V
. The audible alarm devices connected to esserbus
®
PLus
are supplied by the loop voltage and do not need an external power supply
.
Basic data on analog loop of esserbus
®
and esserbus
®
PLus
 Less than 127 loop devices or 127 zone isolators per analog loop
 Analog loop may be divided into 127 individual detector zones (customer data programming)
 No more than 32 analog detectors per detector zone
 Capability of combining loop and spur loop operation. No sub-spur branching!
 Recommended type of cable for analog loop:
Use clearly identified communications cable I-Y (St) Y n x 2 x 0.8 mm or fire alarm cable!
 Max. impedance of the analog loop incl. spur measured with respect to the load factor for IQ8Quad
detectors: max. 3500 m
1)
.
For cable diameter with 0,8 mm and a max. Loop resistance of 130
 (measured from terminal A+ to B+).
 Max. 8 communications transponder per analog loop
max. 16 communications transponder per FACP
 max. 8 Smoke aspirating systems LRS compact/eb or LaserFocus per analog loop
max. 16 Smoke aspirating systems LRS compact/eb or LaserFocus per FACP
 max. 25 Smoke aspirating systems LRS 100 or LRS-S 700 per analog loop,
max. 50 per FACP (System software from Version V3.01 required).
 max. 32 esserbus
®
transponders per analog loop
max. 100 esserbus
®
transponders per FACP
OR
 max. 32 Smoke aspirating systems TITANUS PRO / TOP SENS
®
EB per analog loop.
max. 100 Smoke aspirating systems per FACP.
1)
refer table chapter 5.1.3.
Damage to the system!
It is only possible to operate the esserbus
®
PLus devices compatible with the higher loop
voltage (42 V DC). Mixed operation of Standard and esserbus
®
PLus function within one panel
is not possible ! Loop devices compatible with esserbus
®
PLus (transponders, detectors MCP´s
etc.) are identified by the Part No.
80xxxx.
These 80xxxx devices are also fully compatible to the existing devices with Part No. 78xxxx
and may be used in standard esserbus
®
installations.
