Honeywell XNX Technical Manual

XNX Universal Transmitter
Section 6 - Specications
133
6.2.4 Other EC Sensors
Gas Cartridge P/N
Selectable Full
Scale Range
(Display and
4-20mA Full
Scale)
Default
Range
Range
Incre-
ments
Lower
Alarm
Limit
Lower
Detection
Limit
Zero
Deviation
Selectable
Cal Gas
Range
Default
Cal Point
Response
Time (T50)
sec
Response
Time
(T90) sec
Accuracy
1
Typical
Accuracy
@ Lowest
Alarm
Level
Operating Temperature Operating Humidity
Min Max Min Max
HCl HydrogenChloride XNXXSR1SS 10.0to20.0ppm 10.0ppm 1.0ppm 5.0ppm 0.6ppm -1.0ppm
30to70%
ofthe
selectedfull
scalerange
5.0ppm
<45
2,3
<150
2,3
<+/-1.0ppmor
20%
ofappliedgas
2,3
<+/-1.0@
3ppm
-20°C/-4°F 40°C/104°F 15%RH 90%RH
H
2
S(Low) HydrogenSulfide XNXXSH3SS n/a 15.0ppm n/a 3.0ppm 1.0ppm -2.5ppm 10ppm <20 <40 <+/-0.3ppm
<+/-0.3@
3ppm
-40°C/-40°F 55°C/131°F 15%RH 90%RH
SO
2
SulfurDioxide XNXXSS1SS 5.0to20.0ppm 15.0ppm 5.0ppm 2.0ppm 0.6ppm -1.0ppm 5.0ppm <15 <30 <+/-0.3ppm
<+/-0.3@
2ppm
-40°C/-40°F 55°C/131°F 15%RH 90%RH
SO
2
(High) SulfurDioxide XNXXSS2SS 20.0to50.0ppm 50.0ppm 10.0ppm 5.0ppm 1.5ppm -2.5ppm 25ppm <15 <30 <+/-0.6ppm
<+/-0.6@
5ppm
-40°C/-40°F 55°C/131°F 15%RH 90%RH
NH
3
Ammonia XNXXSA1SS 50to200ppm 200ppm 50ppm 20ppm 6ppm -10ppm 100ppm <60 <180 <+/-4ppm
<+/-4@
20ppm
-20°C/-4°F 40°C/104°F 15%RH 90%RH
NH
3
(High) Ammonia XNXXSA2SS 200to1000ppm 1,000ppm 50ppm 100ppm 30ppm -50ppm 300ppm <60 <180 <+/-20ppm
<+/-20@
100ppm
-20°C/-4°F 40°C/104°F 15%RH 90%RH
Cl
2
Chlorine XNXXSL2SS n/a 5.00ppm n/a 0.50ppm 0.15ppm -0.25ppm 2.0ppm <20 <60 <+/-0.2ppm
<+/-0.20@
0.50ppm
-10°C/14°F 55°C/131°F 15%RH 90%RH
Cl
2
(High) Chlorine XNXXSL1SS 5.0to20.0ppm 5.0ppm 5.0ppm 1.0ppm 0.6ppm -1.0ppm 2.0ppm <20 <30 <+/-0.2ppm
<+/-0.2@
1ppm
-10°C/14°F 55°C/131°F 15%RH 90%RH
ClO
2
ChlorineDioxide XNXXSX1SS n/a 1.00ppm n/a 0.10ppm 0.03ppm -0.05ppm 0.5ppm <30 <120 <+/-30%
<+/-0.03@
0.1ppm
-20°C/-4°F 55°C/131°F 15%RH 90%RH
NO
Nitrogen
Monoxide
XNXXSM1SS n/a 100ppm n/a 10ppm 3ppm -5ppm 50ppm <15 <30 <+/-2ppm
<+/-2.0@
10ppm
-20°C/-4°F 55°C/131°F 15%RH 90%RH
NO
2
NitrogenDioxide XNXXSN1SS 5.0to50.0ppm 10.0ppm 5.0ppm 5.0ppm 1.5ppm -2.5ppm 5ppm <15 <30 <+/-0.2ppm
<+/-0.2@
5ppm
-20°C/-4°F 55°C/131°F 15%RH 90%RH
H
2
Hydrogen XNXXSG1SS n/a 1,000ppm n/a 100ppm 30ppm -50ppm 500ppm <60 <90
2
<+/-8ppm
<+/-8@
100ppm
-20°C/-4°F 55°C/131°F 15%RH 90%RH
H
2
(High) Hydrogen XNXXSG2SS n/a
10,000
ppm
n/a 1000ppm 300ppm -500ppm 5000ppm <15 <30 <+/-150ppm
<+/-150@
1000ppm
-20°C/-4°F 55°C/131°F 15%RH 90%RH
HF HydrogenFluoride XNXXSF1SS n/a 12.0ppm n/a 1.5ppm 0.4ppm -0.6ppm 5.0ppm 120 <240 <+/-0.5ppm
<+/-0.5@
1.5ppm
-20°C/-4°F 55°C/131°F 20%RH 75%RH
PH
3
Phosphine XNXXSP1SS n/a 1.20ppm n/a 0.15ppm 0.04ppm -0.06ppm 0.5ppm <15 <30 <+/-0.02ppm
<+/-0.02@
0.15ppm
-20°C/-4°F 40°C/104°F 10%RH 90%RH
