Section 2 - Installation and Operation
80
Figure 148. Inhibit Menu
Usethe  switchestoinhibitalarmsbyselectingInhibitOn 
withthe
✓
�Theconrmationscreenappears�
Figure 149. Conrm Inhibit On
Select
✓
toplacethetransmitteralarmsintoinhibitmode�Select
✖
willcancelthechoiceandleavethealarmsinnormaloperating
mode�
Figure 150. Conrm Inhibit Off
ToreturnfromInhibitmodetotothenormalmonitoringmode,
selectInhibitOff withthe
✓
�Aconrmationscreenappears�
Select
✓
toremovetheXNXfromInhibitmode�Select‘X”to
cancelthechoiceandleavethealarmsinInhibitmode�

Figure 151. Inhibit Status Screen
WhentheXNXtransmitterisinInhibitmode,theGeneralStatus
displaywilldisplaytheinhibiticon �
Force mA Output
Caution: ThemAoutputsetinthismenuwillreverttothenormal
operatingvalueswhenexitingtheTestMenu.Formoreinformation
onsettingthemAoutputlevelsfornormaloperation,seemA
Levels.
ForcemAOutputallowsperipheraldevicesdrivenbymAoutput
fromtheXNXtransmittertobetested�BasedonthemAoutput
valuessetinthemALevelsoption(seemALevels),theoperator
choosesthemAleveltooutputtothedevice�
Figure 152. Force mA Output Screen
TheNewmAOutputscreenshowsthecurrentmAoutputinthe
leftcolumn�Theoutputcanbecontrolledbychangingthevalue
inthecolumnontheright�
