XNX Universal Transmitter

Section 2 - Installation and Operation

Figure 123. Accepting Path Length Changes

Figure 124. Path Length Changes Accepted

Unit ID

TheUnitIDoptionallowsauniqueunitIDofupto18characters

tobesetforeachXNXtransmitter�Thischaracterstringcanbe

broadcastoveranyofthesupportedcommunicationoptions,

providingameanstocreateauniqueidenticationforeachXNX

transmitterforaccuratereporting�AvailablecharactersareA-Z,

a-z,0-9andspecialcharacters?!*%():&/,#+-



Figure 125. Unit ID Menu

Note: TheXNXUnitIDisnotthesameastheHARTtaginXNX

applicationsusingHARTprotocol.

Edit ID

EachXNXisassignedadefaultUnitIDfromthefactory�TheEdit

IDmenuallowstheassignedIDtobemodied�

Figure 126. Edit Unit ID Screen

FromtheEditIDScreen,usethe  switchesand

✓

toselect

EditID�ThecurrentUnitIDisdisplayed�Wheneditinganexisting

ID,thelistofavailablecharactersbeginsatthevaluedisplayed�

Figure 127. Editing the Unit ID

Usethe

✓

switchtohighlighttherstcharactertobechanged�

Usethe

 switchestodecrementorincrementthevalueuntil

thedesiredvalueappears�Use

✓

toacceptthenewvalueand

movetothenextcharacter�Repeatforeachcharactertobe

changed�TheUnitIDcanbeupto18characterslong�

Clear ID

ThisoptionclearsthecurrentsetUnitID�


