Honeywell XNX Technical Manual

XNX Universal Transmitter
Section 6 - Specications
154
6.4.4 Multi Purpose Detector (MPD)
SimilartotheXNXTransmitter,theMPDpartnumberingsystemdenestheagencyapprovalandthreadtype�Theonlymaterialselection
isStainlessSteel�Foursensorselectionsareavailable�AgencyApprovalsarespecictothe4sensortypes�Ensuretheapprovalof
thespecicsensortypemeetstherequirementsoftheinstallation�
Model Type Port Cong
Installed Sensor Range
(See Section 6.2 for Agency Approvals)
MPD -
q q q q q
AM M25
CB -CatalyticBead%LEL 1 -Default
UT 3/4”NPT
IF -IR%LELFlammable 2 to 9 -Future
BT 3/4”NPT
IV -IRMethane0-5%Vol
IC -RCarbonDioxide0-5%Vol
6.4.5 XNX Catalytic Bead and IR Replacement Sensor Cartridges
Sensor
Type
1, 2
Target Gas
Cartridge
Part No
Operating
Pressure
Range
(kPa)
Operating
Humidity
Range (%
RH non-
condensing)
Air
Speed
(m/s)
Maximum
Range
Selectable
Range
3
Increment
Default
Range
Cal Gas Range Cal Gas P/N
Cal Gas
Description
MPD-IC1 CarbonDioxide 1226-0301 80-110 seefootnote4 0-6 5.00%Vol 1.00to5.00%Vol 1.00%Vol 5.00%Vol 1.50to3.5%Vol
ContactHA
2.5%VOLCO
2
inAir
MPD-IV1
Methane 1226-0299 80-110 0-95 0-6 5.00%Vol 1.00to5.00%Vol 1.00%Vol 5.00%Vol 1.50to3.5%Vol GFV352 2.5%VOLCH
4
inAir
Methane 1226-0299 80-110 0-95 0-6 100%LEL 1.00to5.00%Vol 1.00%Vol 5.00%Vol 1.50to3.5%Vol GFV352 2.5%VOLCH
4
inAir
MPD-IF1 Flammables 1226-0300 80-110 0-95 0-6 100%LEL 20to100%LEL
3
10%LEL 100%LEL 30to70%LEL GFV406 1%VOLC
3
H
8
inAir
MPD-CB1 Flammables 1226A0359 80-120 seefootnote5 0-6 100%LEL 20to100%LEL
3
10%LEL 100%LEL 30to70%LEL GFV352 50%LELCH
4
inAir
1. Agency approved hydrogen sensors are MPD-CB1 and 705 STD.
2. When ordering replacement MPD sensor cartridges, the replacement cartridge must be the same type as factory congured. Substituting a different cartridge
will void agency certication.
3. On XNX %LEL units carrying UL/CSA certications, the range is xed at 100%LEL and is not adjustable.
4. Humidity: 5% to 95% RH non-condensing
5. Humidity: 0 to 99% RH non-condensing
