Honeywell XNX Technical Manual

XNX Universal Transmitter
Section 2 - Installation and Operation
43
2.2.8 mV Personality Wiring
XNXUniversalTransmitterwiththemVpersonalityBoardallows
interfacetoHA’sMultiPurposeDetector(MPD)andeldproven
705andSensepointdevices�
Caution:SeeSection6-Specificationstoensurethatthe
transmitterandthemVsensorhavetheappropriateapprovalsprior
tocommissioning.
Caution: VerifythatthemVsensorbeinginstalledhascompatible
threads(3/4NPTorM25).
ReadSection2�2whichdenestheXNXpowerand4-20mA
outputconnectionsthatarecommontoallpersonalities�
ConnectionsfromthemVSensortotheXNXaremadeviaa
singlepluggableterminalblockallowingeaseofinstallationand
service�HoneywellAnalyticsrecommendsthatan8”(203mm)
servicelengthforwiringbemaintained�Thewirecolorsforthe
connectionsforeachsensortypeareshowninthefollowing
WireColorfromSensortable�
Verifythatwiresfor4-20mAoutputsareroutedawayfrom
sourcesofnoisesuchasrelaywires�
Note:TheblackandredwiresfromtheMPDarenotusedwiththe
XNXmVpersonalityboard.Ensurethattheyareproperlyisolated
fromliveconnections.DoNOTcutthewires.

Caution: DonotforcethePODintotheenclosure.Doingsomay
resultindamagetothewiringorthePODormayaltertheswitch
settings.Ifresistanceisfelt,wiresmaybepreventingthePODfrom
beingproperlypositioned.
Caution: Becertaintodressthewiresproperlytoensurecabling
doesnotcontactswitches1-2onthebackofthePOD.

