Honeywell XNX Technical Manual

XNX Universal Transmitter
Section 2 - Installation and Operation
87
RelayDatadisplaysthecurrentsettingoftheoptionalrelayson
thetransmitter�Tochangetherelaysettings,seeRelayOptions�
?
Event History
TheEventHistoryscreenlistsalleventsthatareactivatedby
thetransmitter’ssettings�Fivetypesofeventsarerecorded:
resetmessages,alarmmessages,warningmessages,fault
messages,andinformationalmessages�Theeventsarelistedin
chronologicalorderbeginningwiththelatest�
Eventscanbedisplayedthroughvebrowsingmodes:
• alleventsinorderofoccurrence
• alleventsbyhour
• alleventsbyday
• onlythealarmevents,inorderofoccurrence
• onlythefaultevents,inorderofoccurrence
TheEventHistoryscreengroupseventsintochronologicalorder
(beginningfromtheunit’sinstallation)�Eventscanalsobeviewed
byhourorbydate�
Eventslistedin
hour orderaregroupedwithoutregardtodate�
Forexample,alleventsthathaveoccurredbetweennoonand
1:00o’clocksincethetransmitter’sinstallationcanbeisolated�
Toviewalleventsinhourorder:
1� Usethemagneticwandtolterthedisplaybyhour�
2� Navigatethroughthedisplayedtimes�
Toisolatealloftheeventsfromaspecic
day :
1� Usethemagneticwandtolterthedisplaybyday�
2� Navigatethroughthedisplayeddays�
3� Filterthelistbyallevents�Thiswilldisplayalleventsthat
occurredonthatday�
WhenthetransmitterisconguredwiththeSearchlineExcelor
SearchpointOptima,thedatareportedintheeventwillbethe
faultcodefromtheSearchlineExcelorSearchpointOptima�
Thetransmitterrecordsupto1280eventsinacircularbuffer�
Whenevent1281isrecorded,theoldesteventwillbebumped
fromthelist�
Note: Theleadingzerosoffaultsandwarningsarenotdisplayed
intheeventlist;i.e.,Fault011willbedisplayedasFault11.
Figure 187. Event History Screen
 
Figure 188. Chronological Event List
 
Figure 189. Chronological Event List by Hour
