80
Figure 24 Network diagram for configuring source IP-based login control over NMS users
Configuration procedure
# Create ACL 2000, and configure rule 1 to permit packets sourced from Host B, and rule 2 to permit
packets sourced from Host A.
<Sysname> system-view
[Sysname] acl number 2000 match-order config
[Sysname-acl-basic-2000] rule 1 permit source 10.110.100.52 0
[Sysname-acl-basic-2000] rule 2 permit source 10.110.100.46 0
[Sysname-acl-basic-2000] quit
# Associate the ACL with the SNMP community and the SNMP group.
[Sysname] snmp-agent community read aaa acl 2000
[Sysname] snmp-agent group v2c groupa acl 2000
[Sysname] snmp-agent usm-user v2c usera groupa acl 2000
Configuring source IP-based login control over web
users
You can log in to the web management page of the device through HTTP/HTTPS to remotely manage the
devices. By using the ACL, you can control web user access to the device.
Configuration preparation
Before configuration, determine the permitted or denied source IP addresses.
Configuring source IP-based login control over web users
Because basic ACLs match the source IP addresses of packets, you can use basic ACLs to implement
source IP-based login control over web users. Basic ACLs are numbered from 2000 to 2999. For more
information about ACL, see the ACL and QoS Configuration Guide.
Follow these steps to configure source IP-based login control over web users:
To do… Use the command…
Remarks
Enter system view system-view —
