169
Down Imaging
CHANGE THE DOWN IMAGING VIEW OVERLAYS
U
se the Overlays menu to display or hide information on the view. In the Down Imaging View, you can display the following: depth
r
ange, beam frequency label, and data overlays. Digital readout data can be displayed as an overlay, and it can be displayed in the
d
ata bar. To turn on the data bar, see Views: Display a Data Bar. For more information about data overlays, see Views.
1. With a Down Imaging View displayed on-screen, tap Sonar (DI) in the status bar, or press the MENU key once.
2. Select Sonar Options.
3. Select Overlays.
4. Tap the menu, or use the Joystick to select an item, and add a check mark. (check mark = visible, blank = hidden).
Selecting Overlays for the Down Imaging View
frequency
label
data overlays
depth line
depth range
shows
incremental
marks
between the
upper and
lower depth
range
