177
Sonar Recording
SONAR RECORDING
U
se the Sonar Recording menu to record active sonar information. Sonar recordings are saved to an installed SD card, and you can
p
lay your saved sonar recordings from the Recordings tool. When the recording is played back, the views that were active during
t
he recording are available. You can also adjust the view settings and mark waypoints during playback.
Start Recording
When you start a sonar recording, you can select which beams will be recorded and where the sonar recording will be saved. Sonar
Recording can be started from the Sonar X-Press Menu or the Recordings tool. The instructions for the Sonar
X-Press Menu are shown here.
1. With a Sonar View (2D, SI, DI) displayed on-screen, tap Sonar in the status bar.
OR
Press the MENU key once.
2. Select Sonar Recording.
3. Set up the sonar recording:
Select Recording Sources, and select the beams to be recorded.
Select Save Location, and select an installed SD card.
4. Select Start Recording.
Stop Recording
1. Press the MENU key once.
2. Select Sonar Recording.
3. Select Stop Recording.
Play a Sonar Recording
1. Press the HOME key.
2. Select the Recordings tool.
3. Tap the recording name, or use the Joystick to select it.
4. Select Start.
Open the Playback Control Menu
The Playback Control menu includes stop, pause, forward or reverse for the recording played on the screen.
1. Play a sonar recording.
2. With a Sonar View (2D, SI, DI) displayed on-screen, tap Sonar in the status bar.
OR
Press the MENU key once.
3. Select Sonar Playback.
