Ihse Draco tera 480 Series User Manual

Configuration
2020-02-26 113
5.5.3 User Macros
In this menu macro commands for switching, disconnection or user
administration can be created. Macro commands are created for each
user separately.
A macro can execute up to 16 switching commands successively.
The execution of the macros is done via 'Hot Key' and the <F1>-<F16>
function keys (see Chapter 6.1.3, Page 206).
In order to execute user macros the user has to be logged in to the matrix.
You can select the following settings:
Field
Selection
Description
Function
(01–16)
Connect
(P1=CON,
P2=CPU)
Set bidirectional connection from
console P1 to CPU P2
Connect Video
(P1=CON,
P2=CPU)
Set video connection from console P1
to CPU P2
Disconnect
(P1=CON)
Disconnect console P1
Logout User
Logout current user
Set Real CPU
(P1=VCPU,
P2=RCPU)
Assign a virtual CPU to a real CPU
Set Virtual CON
(P1=RCON,
P2=VCON)
Assign a real console to a virtual
console
Push (P1=CON)
The user’s KVM connection is
forwarded to console P1 and is
changed to a video only connection.
Push Video
(P1=CON)
The video signal of the current
connection (KVM or video only) is
forwarded to console P1. The user’s
connection remains unchanged (KVM
or video only).
