Draco tera

20 2020-02-26

Pos: 20 /806-IHSE/ Beschreibu ng/Geräteansich ten/480-xx/Dr aco tera 152 Port @ 25\mod _158097086037 4_6.doc @ 271 785 @ 3 @ 4

3.6.4 Draco tera 152 Port

Front View

1 Slot for power supply unit 1

2 Slot for fan tray 1

3 Slot for power supply unit 2

4 Slot for fan tray 2

5 Slots for I/O boards #1–20

6 Slot for power supply unit 3

7 Grounding

8 Slot for CPU board (redundancy)

9 Slot for CPU board
