Configuration
2020-02-26 125
7. The USB 2.0 CPU extenders now has to be either assigned to an
existing CON Device in the Extender & Devices > CPU Devices
menu or a new CON Device has to be created for the assignment by
pressing the New Device button.
8. If you use parallel operation within the matrix, set the Release Time
in the System Settings > Switch menu to 10 s or more (see Chapter
5.13.6, Page 158).
9. Restart all I/O boards on which USB 2.0 extenders have been
configured or alternatively restart the matrix.
The USB 2.0 extenders are now configured and can be used.
Created extender units are always set as fixed port extenders. This
configuration is necessary if you want to switch e.g. USB 2.0 connections
via the matrix.
In order to make a fixed port available again for Flex-Port extender units
after deleting a fixed port extender unit, a restart of the I/O board is
necessary.
Pos: 77 /806-IHSE/ Konfiguration /480_UNI-E/ A-Karten/Extend er für UNI-E-A- Karten anlege n @ 10\mod_ 1389086670086 _6.doc @ 1131 49 @ 2 @ 4
5.8 Extenders for UNI I/O Boards (USB 2.0 /
USB 3.0)
This chapter will help you to configure and use your USB 2.0/3.0
extenders. For the use of USB 3.0 extenders you need at least one UNI
I/O board and SFP modules based on 6.25 Gbit/s for the matrix.
You have the following options to configure the system:
