Draco tera
68 2020-02-26
5.2.2 Control via Java Tool
Requirements
If you want to use the Java Tool, the following requirements have to be
fulfilled:
Computer with an executable Java Tool and an installed Java
Runtime Environment (JRE, version 1.7 or higher)
Java Tool software
Available network connection between the Java Tool and the matrix
Contact your system administrator concerning JRE and network
connection.
Installation of the Java Tool
The Java Tool is available as a single executable program file that does
not require a separate installation.
➔ Copy the tool after receiving the file to a directory on your computer.
If you do not have a copy of the Java Tool, contact your dealer.
Computer Connection to the Matrix
For a direct connection between computer and matrix, a cross-wired
network cable is required.
For a connection between computer and matrix via switch or hub, a
parallel assembled network cable is required.
Do not use a network connection between Java Tool and the matrix that is
primarily used for transmitting audio data.
➔ Connect the network cable to the RJ45 ports of computer and CPU
board of the matrix.
Start of the Java Tool
➔ Open the Java Tool by a double click on the program icon or use the
<Enter> key of the keyboard.
