3.6.5 Draco tera 80 Port

Front View

1 Slot for fan tray

2 Slot for power supply unit 1

3 Slots for I/O boards #1–10

4 Slot for power supply unit 2

5 Slot for CPU board

6 Slot for air filter

7 Slot for fan tray 2
