Specifications
2020-02-26 235
7 Specifications
Pos: 143 /806-IHS E/Technisch e Daten/Schnittst ellen/UEB_Schnit tstellen @ 5 \mod_1278 578201870_6.d oc @ 42114 @ 2 @ 1
7.1 Interfaces
Pos: 144 /806-IHS E/Technisch e Daten/Schnittst ellen/DVI-D-Si ngle-Link @ 5\mod_12785 78254058_6.doc @ 42132 @ 3 @ 1
7.1.1 DVI-D Single Link
The video interface supports the DVI-D protocol. All signals that comply
with DVI-D Single Link norm can be transmitted. This includes monitor
resolutions such as 1920x1200@60Hz, Full HD (1080p) or 2K HD (up to
2048x1152). Data rate is limited to 165 MPixel/s.
Pos: 145 /806-IHS E/Technisch e Daten/Schnittst ellen/USB-H ID @ 5\mod_1 278578292214_ 6.doc @ 42150 @ 3 @ 1
7.1.2 USB-HID
Our devices with USB-HID interface support a maximum of two devices
with USB-HID protocol. Each USB-HID port provides a maximum current
of 100 mA.
Keyboard
Compatible with most USB keyboards. Certain keyboards with additional
functions may require custom firmware to operate. Keyboards with an
integral USB Hub (Mac keyboards e.g.) are also supported.
Mouse
Compatible with most 2-button, 3-button and scroll mice.
Other USB-HID devices
The proprietary USB emulation also supports certain other USB-HID
devices, such as specific touch screens, graphic tablets, barcode
scanners or special keyboards. Support cannot be guaranteed, however,
for every USB-HID device.
Extension
If it is required to extend the USB-HID signals on CON or CPU side (e.g.
mounting requirement), the signals can be extended either via a 3.0 m A-
B cable (247-U2) or a 3.0 m USB A-A extension cable (436-USB20).
The compatibility to other extension cables cannot be guaranteed.
Only two USB-HID devices are supported concurrently, such as keyboard
and mouse or keyboard and touch screen. A hub is allowed, but it does
not increase the number of HID devices allowed.
To support other USB 'non-HID' devices, such as scanners, web cams or
memory devices, choose our devices with transparent USB support.
