Specifications
2020-02-26 237
7.1.7 SDI (Interconnect)
Communication of the SDI devices requires a mini coax connection with
HD-BNC connectors or 3G SFPs with transmission speeds of 0.36 Gbit/s
(SD-SDI, SMPTE 259M), 1.485 Gbit/s (HD-SDI, SMPTE 292M) and
2.97 Gbit/s (3G SDI).
Pos: 151 /806-IHS E/Technisch e Daten/Verbi ndungskabel/UE B_Verbindungsk abel @ 5\m od_12791911 07845_6.doc @ 4 3870 @ 2 @ 1
7.2 Interconnect Cable
Pos: 152 /806-IHS E/Technisch e Daten/Verbi ndungskabel/Verbi ndungskabel (C at X) @ 5\m od_12785784 06026_6.doc @ 42205 @ 3 @ 1
7.2.1 Cat X
A point-to-point connection is required. Operation with several patch fields
is possible. Routing over an active network component, such as an
Ethernet Hub, Router or Matrix, is not allowed.
➔ Avoid routing Cat X cables along power cables.
To maintain regulatory EMC compliance, correctly installed shielded Cat X
cable must be used throughout the interconnection link.
To maintain regulatory EMC compliance, all Cat X cables need to carry
ferrites on both cable ends close to the device. Failure to do so will result
to invalidity of the EU declaration of conformity.
Type of Interconnect Cable
The Draco tera requires interconnect cabling specified for Gigabit Ethernet
(1000BASE-T). The use of solid-core (AWG24), shielded, Cat 5e (or
better) is recommended.
Cat X Solid-Core Cable
AWG24
S/UTP (Cat 5e) cable according to EIA/TIA-
568-B. Four pairs of wires AWG24.
Connection according to EIA/TIA-568-B
(1000BASE-T).
Cat X Patch Cable
AWG26/8
S/UTP (Cat 5e) cable according to EIA/TIA-
568-B. Four pairs of wires AWG26/8.
Connection according to EIA/TIA-568-B
(1000BASE-T).
The use of flexible cables (patch cables) type AWG26/8 is possible,
however the maximum possible extension distance is halved.
Pos: 153 /806-IHS E/Technisch e Daten/Verbi ndungskabel/Verbi ndungskabel (C at X)_Kabelläng e 477-xx @ 5\mod_1278 937761105_6.d oc @ 43167 @ @ 1
