Description
2020-02-26 31
Pos: 29 /806-IHSE/ Beschreibu ng/Status/Port-St atus/480-xx @ 7\mod_1309 935423961_6.d oc @ 52661 @ 3 @ 4
3.7.2 Port Status
The connections and the switching status between the various consoles
and CPUs are shown in this menu.
You have the following option to access the menu:
Java Tool
The current port configuration of the Draco tera is illustrated in this menu.
➔ Select View > Matrix in the task area when connected to the matrix.
Menu View - Matrix (example #1)
