Ihse Draco tera 480 Series User Manual

Draco tera
250 2020-02-26
9 Troubleshooting
Pos: 180 /806-IHS E/Hilfe im Pro blemfall/Hilfe im Problemfall ( 480-xx) @ 7\mo d_1309943 852774_6.doc @ 54002 @ @ 1
In the following chapters, support for problems with the Draco tera matrix
is provided. It is assumed that fully operational CPU and CON Devices are
available, which can be tested over a peer-to-peer connection using Cat X
or fibre cables. Please refer to the relevant manuals for assistance with
this if necessary.
Pos: 181 /806-IHS E/Hilfe im Pro blemfall/Extern e Störung/48 0-xx @ 7\mod _1309944289 555_6.doc @ 5402 1 @ 2 @ 1
9.1 External Failure
Diagnosis
Possible Reason
Measure
Matrix cannot be
started
anymore.
Fuse at the standard
appliance outlet.
➔ Check fuse.
Pos: 182 /806-IHS E/Hilfe im Pro blemfall/Bildstöru ng/480-xx @ 7\mod_130 9944461727_ 6.doc @ 54076 @ 2 @ 1
9.2 Video Interference
Diagnosis
Possible Reason
Measure
Opening the
OSD not
possible
No OSD jumper set
➔ Set jumper 11 on the CON unit.
Incorrect video
display
Cable connection
disturbed
➔ Check the connection, length
and quality of the interconnect
cable to the units.
Pos: 184 /806-IHS E/Hilfe im Pro blemfall/Lüfterst örung/480-x x @ 7\mod_1 309944511868_6. doc @ 54095 @ 2 @ 1
9.3 Malfunction of Fans
Diagnosis
Possible Reason
Measure
Fans only run
under full load
Communication to fan
tray is not working
➔ Remove and reinstall fan tray.
➔ Swap both fan trays to the other
slot.
➔ Restart the matrix.
Fans do not
run, LED OK on
Fans defective
➔ Contact your dealer.
Fans do not
run, LED OK off
Power supply
➔ Check power supply and power
connection.
Pos: 185 /806-IHS E/Hilfe im Pro blemfall/Störu ng der Netzteile/4 80-xx @ 7\mo d_1309944 565727_6.doc @ 54114 @ 2 @ 1
