7.1.7 S-Plan wiring diagram
X15
(24V=)
X14
X13
(24V =)
X12
(24V =)
X11
(24V =)
N/A
X10
(24V =)
N/A
X8
(230V ~)
X5
(230V ~)
X4
(230V ~)
X3
(230V ~)
X2
(230V ~)
X1
(230V ~)
F1 (3,15 AT)
FUSE
23 1
24V=
230V


Zone Valve
D H W
V4043H
(normally closed)
Room
thermostat
230Vac 3amp
Switched
Fused Spur
Wiring Centre
Zone Valve
C/HEATING
V4043H
(normally closed)
Twin channel
Programmer
L
N
HTG on
EARTH
S/L TO BOILER (DHW) P/LIVE
M/V/S/L
NEUTRAL
EARTH
L N
Cylinder
thermostat
NEUTRAL
DHW on
2
1
3
1
C
1 2
3 4 5 6 7 8 9 10
S/L TO BOILER (HTG)
P/LINE M/V/S/L DHW S/L
HTG S/L
S/LIVE (BOILER)
Note:-
With all wiring diagrams when using a digital type room thermostat the Neutral wire from the
wiring centre (2) to room thermostat (2) will not be required.
LIVE SUPPLY
