JR XP6102 User Manual

CHAPTER 5: SYSTEM MODE • AIRPLANE
NORMAL MODE
5.1
When the power switch is in the On
position, the display will read as follows:
17XP6102 - Airplane Manual
[MODEL SEL]
#4 PLANE SPCM
ALPHA 40
TOTAL T 0:05:27
To enter and exit the System mode, press
simultaneously then turn on the power switch.
To enter and exit the Function model, turn on
the power switch, then press simultaneously.
Elevator Trim
Aileron Trim
Rudder Trim
Throttle Trim
Modulation Type
Model Type
Model Number
Transmitter
"On Time"
Model Name
SYSTEM MODE
5.2
To enter the System mode, press the
Down and Select keys simultaneously,
then turn the power switch to the on
position. The display will show the last
active program. Pressing either the Up or
Down key then scrolls through the
functions one by one, according to the
system mode flowchart shown to the right.
Once the appropriate function is
displayed, changes can be made by
pressing the (+) or (-) keys.
System Mode Flowchart
Information pertaining to each function is
explained on the page listed next to the
function name. Functions will appear in
the same order they are shown on
this chart.
Accessing the System Mode
1. Press the Down and Select keys
simultaneously.
2. Move the power switch to the On
(upper) position.
3. Use either the Up or Down key to
scroll through the menu and access the
applicable function.
[MODEL SEL]
#4 PLANE SPCM
ALPHA .40
TOTAL T 0:05:27
[MODEL NAME]
#5 PLANE SPCM
ALPHA 40
[MODEL TYPE]
#5 ALPHA 40
AIRPLANE
DATA RESET
[MODEL COPY]
#5 ALPHA 40

#6 PLANE SPCM
[MODULATION]
#5 ALPHA 40

SPCM
[TRAINER]
#5 ALPHA 40
NORMAL
[SWITCH SEL]
D/R INDIVID
GEAR RIGHT SW
FLAP FLAP LVR
[WING TYPE]
FLAPERON OFF
ELEVON OFF
V-TAIL OFF
Model
Selection
pg 18
Model
Name
Entry
pg 19
Model
Type
pg 20
Model
Copy
pg 21
Modu-
lation
pg 22
Trainer
pg 23
Switch
Select
pg 24
Wing
Type
pg 25
