3.3
SERVO SPECIFICATIONS
TYPE 537
TORQUE (ounce inch) 43 oz/in
SPEED (sec/60°) .25 60°
WEIGHT 1.58
SIZE (in) (L x W x H) 1.52 x 0.73 x 1.32
BB Single
MOTOR 3-Pole Ferrite
8 XP6102 - Introduction
3.4
RECEIVER SPECIFICATIONS
TYPE FM PCM
MODEL NUMBER R700 R770
TYPE 7 Channel / FM-ABC&W / Micro 7 Channel / FM-ABC&W / Micro
FREQUENCY 72MHz 72MHz
SENSITIVITY (Microseconds) 5 uS minimum 5 uS minimum
SELECTIVELY 8KHz / 5 dB 8KHz / 5 dB
WEIGHT (oz) 1.5 1.5
RECEIVER ANTENNA 39“ for all aircraft frequencies 39“ for all aircraft frequencies
3.5
CHARGER SPECIFICATIONS
TYPE AIRCRAFT HELICOPTER
MODEL NUMBER NEC-222 NEC-222
INPUT VOLTAGE AC 100–120V AC 100–120V
OUTPUT CURRENT 50mAh TX/120mAh RX 50mAh TX/120mAh RX
CHARGING TIME 15 Hours 15 Hours
3.6
AIRBORNE BATTERY PACK
TYPE AIRCRAFT HELICOPTER
MODEL NUMBER B1100 B1100
VOLTAGE 4.8 V 4.8 V
SIZE (in) (W x L x H) 2.24 x 0.63 x 1.70 2.24 x 0.63 x 1.70
WEIGHT (oz) 4.9 4.9
