6.6
ELEVATOR TO FLAP MIXING
When this system is active and a value of
flaps is input, the flaps will be deflected
each time the elevator stick is used. The
actual flap movement is adjustable for
both up and down elevator. The most
frequently used application is up
elevator/down flaps and down elevator/up
flaps. When used in this manner, the
aircraft pitches much more quickly than
normal. The upper-most position of the
Flap Mixing switch activates the Elevator-
to-Flap Mixing circuitry.
34 XP6102 - Airplane Manual
Accessing the Elevator to Flap Function
1. Place the transmitter power switch in
the On position.
2. Access the Function mode. To do so,
press the Down and Select keys
simultaneously.
Press either the Up or Down key until
ELE ➔ F MX appears in the upper
portion of your LCD.
3. Move the elevator stick in the direction
you want to mix with flaps.
Note: The position indicator will reflect
this change by highlighting the up or
down arrow.
5. Press the (+) or (-) key to increase or
decrease the amount of flaps to be
mixed. If you want to reverse the flap
travel, press the Clear key, bringing the
mixing value to the factory default (0%),
and increase the value using the
opposite key (+) or (-) from the key
originally selected.
6. Once you have adjusted the first
mixing position (up or down), place the
elevator stick in the opposite direction
and follow Step 5 above to adjust the
second elevator mixing value.
7. Access the switch position by pressing
the Select key. Use the (+) or (-) keys to
select from the one of six switches, or
from always on.
8. Access the TRAVEL ADJ function by
pressing the Down key.
9. Access the AIL ➔ RUD MIX Mixing
function by pressing the Up key.
10. Exit the ELE ➔ F MX function by
pressing the Down and Channel keys
simultaneously.
