AILERON TO RUDDER MIXING
6.7
This form of mixing is designed so that
when input to the aileron stick is given,
the rudder servo will also move,
eliminating the need to coordinate these
controls manually.
When adjusting, if an opposite mixing
direction of the rudder servo is required,
simply press the (+) or (-) keys to change
the mixing value from a (+) to (-) or a
(-) to a (+). This will reverse the mixing
direction of the rudder from its original
direction. The switch used to activate this
mix can also be selected as explained
below. The factory default is always on
with a value of 0%.
35XP6102 - Airplane Manual
Accessing the Aileron to Rudder Mixing Function
1. Place the transmitter power switch in
the On position.
2. Access the Function mode. To do so,
press the Down and Select keys
simultaneously. Press either the Up or
Down key until AIL ➔ RUD MIX
appears in the center portion of your
LCD.
3. Press the (+) or (-) key to increase or
decrease the amount of rudder to be
mixed with aileron. If you want to
reverse the Rudder Mix direction, press
the Clear key, bringing the mixing value
to the factory default (0%), and increase
the value using the opposite key (+) or (-
) from the key originally selected.
4. Press the Select key to access the
switch assignment function.
5. Press the (+) or (-) key to select the
desired switch/function to activate the
Aileron-to-Rudder Mixing function.
6. Access the ELE ➔ FLP MX mixing
function by pressing the Down key.
7. Access the THRO CUT function by
pressing the Up key.
8. Exit the AIL ➔ RUD MIX function by
pressing the Down and Select keys
simultaneously.
