FX-3R Maintenance Guide

9-2

[U] button

[V] button

[LED] panel

[SET] button

Figure 9-1-1-1 Digital Pressure Switch

1) Setting the display mode and hysteresis mode

c Keep the

button pressed for 2 sec. or longer. The display will become . (The

operation enters the display color setting mode.)

d Press the

or button to display . After that, press the button.

(When the switch is turned ON, this is displayed in green.)

e Press the

or button to display . After that, press the button. (The

operation enters the hysteresis setting mode.)

f Press the

or button to display . After that, press the button. (The

normally open operation is set.)

g Press the

or button to display . After that, press the button. (The

response time is set at 2.5 ms or less.)

h Press the

or button to display . After that, press the button. (The

manual set mode is set.)

i The numeric value is displayed in this step, and then the operation is returned to the

measurement mode.

2) Setting a detection level (threshold value and hysteresis)

c In the measurement mode, press the

button. and current threshold value are

displayed alternately.

d Press the

or button. The numeric value at the least significant digit starts flashing.

Subsequently, press the

or button to increase or decrease the numeric value.

e When pressing the

button, the flashing digit moves left.

f Perform operation steps d and e to display

. Keep the button pressed for 2

sec. or longer. (The threshold value is then set to “0.400 MPa”.)

and current set value are displayed alternately. Press the button.

and current hysteresis value are displayed alternately.

i Press the

or button. The numeric value at the least significant digit starts flashing.

Subsequently, press the

or button to increase or decrease the numeric value.

j When pressing the

button, the flashing digit moves left.

k Perform operation steps h and j to display

. Keep the button pressed for 2

sec. or longer. (The hysteresis value is then set to “0.050 MPa”.)

l The operation is then returned to the measurement mode. The settings are then completed.

Rev. 1.00
