6: Instrument programming Series 2600B System SourceMeter® Instrument
6-32 2600BS-901-01 Rev. B / May 2013
Figure 112: Example of the Test Script Builder workspace
Item Description
Script editor; right-click to run the script that is displayed
3 Outline view
Help; includes detailed information on using Test Script Builder
Project navigator
The project navigator consists of project folders and the script files (.tsp) created for each project.
Each project folder can have one or more script files.
To view the script files in a project folder, click the plus (+) next to the project folder. To hide the folder
contents, click the minus (−) next to the project folder.
You can download a TSP project to the instrument and run it, or you can run it from the TSB
interface.
