Bit B15 B14 B13 B12 B11 B10 B9 B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal 32,768 16,384 8,192 4,096 2,048 1,024 512 256
Weights
(2
15
) (2
14
) (2
13
) (2
12
) (2
11
) (2
10
) (2
9
) (2
8
)
Example 1
operationRegister = status.operation.instrument.SMUA +
status.operation.instrument.TRGBLND
status.operation.instrument.enable = operationRegister
Sets bit B1 and bit B10 of the
operation status instrument
summary enable register using
constants.
Example 2
-- 1026 = binary 0000 0100 0000 0010
operationRegister = 1026
status.operation.instrument.enable = operationRegister
Sets bit B1 and bit B10 of the
operation status instrument
summary enable register using
a decimal value.
Also see
Operation Status Registers (on page E-9)
status.operation.* (on page 7-270)
Condition register sets of:
• status.operation.instrument.digio.* (on page 7-275
)
• status.operation.instrument.lan.* (on page 7-278)
• status.operation.instrument.trigger_blender.* (on page 7-286)
• status.operation.instrument.trigger_timer.* (on page 7-289)
• status.operation.instrument.tsplink.* (on page 7-293)
status.operation.instrument.digio.*
This attribute contains the operation status digital I/O summary register set. This attribute is not available on the
Models 2604B/2614B/2634B.
Type TSP-Link accessible Affected by Where saved Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
1024 (All bits set)
Usage
operationRegister = status.operation.instrument.digio.condition
operationRegister = status.operation.instrument.digio.enable
operationRegister = status.operation.instrument.digio.event
operationRegister = status.operation.instrument.digio.ntr
operationRegister = status.operation.instrument.digio.ptr
status.operation.instrument.digio.enable = operationRegister
status.operation.instrument.digio.ntr = operationRegister
status.operation.instrument.digio.ptr = operationRegister
operationRegister
The status of the operation status digital I/O summary register; a zero (0) indicates
no bits set (also send 0 to clear all bits); the only valid value other than 0 is 1024
