Keithley 2614B Reference Manual

Series 2600B
System SourceMeter® Instrument Reference Manual Appendix C:
LAN concepts and settings
2600BS-901-01 Rev. B / May 2013 C-15
Confirming port numbers
To view the port number assigned to each remote interface protocol:
1. From the front panel, press the MENU key, and then select LAN > STATUS > PORT.
2. Use the navigation wheel to select one of the following:
• RAW-SOCKET
• TELNET
• VXI-11
• DST
1. Press the ENTER key to view the port number.
2. Press the EXIT (LOCAL) key once to return to the PORT menu.
The following table displays the remote interface protocols supported by the Series 2600B and their
assigned port numbers.
Port number
Command interface Port number
Raw socket
5025
Telnet
23
VXI-11
1024
DST (dead socket termination)
5030
Selecting a LAN interface protocol
This section provides details about how to select a remote interface protocol to connect to the Series
2600B. The Series 2600B provides three LAN interfaces with three associated LAN protocols (each
interface uses a different protocol). Select the interface based on the protocol needed. The dead
socket termination interface (DST) is provided to solve connection problems; it is not a protocol
choice.
VXI-11 connection
This remote interface is similar to GPIB and supports message boundaries, serial poll, and service
requests (SRQs). A VXI-11 driver or NI-VISA
TM
software is required. Test Script Builder (TSB) uses
NI-VISA and can be used with the VXI-11 interface. You can expect a slower connection with this
protocol.
