Keithley 2614B Reference Manual

Series 2600B
System SourceMeter® Instrument Reference Manual Section 7:
TSP command reference
2600BS-901-01 Rev. B / May 2013 7-327
Bit B7 B6 B5 B4 B3 B2 B1 B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
) (2
6
) (2
5
) (2
4
) (2
3
) (2
2
) (2
1
) (2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
)
(2
14
)
(2
13
)
(2
12
)
(2
11
)
(2
10
)
(2
9
)
(2
8
)
Example 1
enableRegister = status.system4.NODE53 +
status.system4.NODE56
status.system2.enable = enableRegister
Uses constants to set bit B11 and bit B14
of the system summary 4 enable
register.
Example 2
-- decimal 18432 = binary 0100 1000 0000 0000
enableRegister = 18432
status.system4.enable = enableRegister
Uses a decimal value to set bit B11 and
bit B14 of the system summary 4 enable
register.
Also see
status.system3.* (on page 7-323)
status.system5.* (on page 7-327)
System summary and standard event registers (on page E-7)
status.system5.*
These attributes manage the TSP-Link
®
system summary register of the status model for nodes 57 through 64.
These attributes are not available on the Models 2604B/2614B/2634B.
Type TSP-Link accessible Affected by Where saved Default value
Attribute
- -
- -
- -
- -
.condition (R)
Yes
Not applicable
Not saved
Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW)
Yes
Status reset
Not saved
0
.ptr (RW)
Yes
Status reset
Not saved
510 (All bits set)
Usage
enableRegister = status.system5.condition
enableRegister = status.system5.enable
enableRegister = status.system5.event
enableRegister = status.system5.ntr
enableRegister = status.system5.ptr
status.system5.enable = enableRegister
status.system5.ntr = enableRegister
status.system5.ptr = enableRegister
enableRegister
The status of the system summary 5 register; a zero (0) indicates no bits set; other
values indicate various bit settings
