Keithley 2614B Reference Manual

Section
7: TSP command reference Series 2600B System SourceMeter® Instrument
Reference Manual
7-70 2600BS-901-01 Rev. B / May 2013
Details
Set display.locallockout to display.LOCK to prevent the user from interrupting remote operation by
pressing the EXIT (LOCAL) key.
Set this attribute to display.UNLOCK to allow the EXIT (LOCAL) key to interrupt script or remote operation.
Example
display.locallockout = display.LOCK
Disables the front-panel EXIT (LOCAL) key.
Also see
None
display.menu()
This function presents a menu on the front panel display.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
selection = display.menu(name, items)
selection
Name of the variable that holds the selected menu item
name
Menu name to display on the top line
items
Menu items to display on the bottom line
Details
The menu consists of the menu name string on the top line, and a selectable list of items on the bottom line. The
menu items must be a single string with each item separated by whitespace. The name for the top line is limited
to 20 characters.
After sending this command, script execution pauses for the operator to select a menu item. An item is selected
by rotating the navigation wheel to place the blinking cursor on the item, and then pressing the navigation
wheel (or the ENTER key). When an item is selected, the text of that selection is returned.
Pressing the EXIT (LOCAL) key will not abort the script while the menu is displayed, but it will return nil. The
script can be aborted by calling the exit function when nil is returned.
Example
selection = display.menu("Menu", "Test1 Test2 Test3")
print(selection)
Displays a menu with three
menu items. If the second menu
item is selected, selection is
given the value Test2.
Output:
Test2
Also see
None
