11-2
Repair manual KTM LC8 Art.-No. 3.206.035-E
Engine LC8
Design
Liquid-cooled, 2-cylinder 4-stroke engine with 75° V arrangement with balancer shaft and electric starter
Displacement 942 cm3
Bore / Stroke 100/60 mm
Compression ratio 11.5:1
Fuel unleaded premium fuel with at least RON 95 (ROZ 80 - 94 for other ignition curve)
Valve timing 4 valves controlled over bucket tappet and 2 camshafts, camshaft drive with gears/chain
Valve diameter Intake: 38 mm Exhaust: 33 mm
Valve clearance, cold Intake: 0,10 - 0,15 mm Exhaust: 0,25 - 0,30 mm
Crankcase bearing Friction bearings (2 main bearings / 1 supporting bearing)
Conrod bearing Friction bearing
Piston pin bearing Dual-fuel bearing
Piston Light alloy – forged
Piston rings 1 compression ring, 1 taper face ring, 1 single-piece oil scraper ring with spiral-type expander
Engine lubrication Dry sump with 2 trochoidal pumps (pressure pump and suction pump)
Engine oil SAE 5W/40, 10W-50 (f.ex. Motorex Power Synt 4T)
Quantity of engine oil approx. 3.0 liters during oil/filter change or approx. 3.3 liters for dry engine
Primary drive Straight-toothed spur wheels 35:67
Clutch Multi-disc clutch in oil bath
Transmission 6-speed claw shifted
Gear ratio 1st gear 12:35
2nd gear 15:32
3rd gear 18:30
4th gear 20:27
5th gear 24:27
6th gear 26:27
Ignition system breakerless transistorized electronic ignition system with digital ignition advance
Ignition timing 5° from TDC at 1200 rpm
Generator 12V 450W at 6000 rpm
Spark plug NGK CR 8 EK
Electrode distance 0.7 mm
Cooling system liquid cooled, permanent circulation of cooling liquid through water pump
Cooling liquid 2.1 liters, 50% antifreeze, 50% destilled water, at least –25° C
Starting aid 0.9 kW electric starter
TECHNICAL SPECIFICATIONS – ENGINE 950 ADVENTURE
950 LC8 ADVENTURE
Type of carburetor CVRD 43
Main jet 155 (front) / 160 (rear)
Main air jet 40
Idling jet 42
Idle air jet 50
Idle air cutoff jet 80
Jet needle NDFB
Needle position 2nd from top
Mixture control screw open 2 1/4 turns
Starting jet 68
BASIC CARBURETOR SETTING
