Connector BZ2
3-pole
3
Ambiant air pressure
sensor
Behind the headlight
mask
Connector BZ1
3-pole
2
Manifold air pressure
sensor for front cylinder
On the right side of the
frame
Connector BZ
3-pole
1
Pressure sensor for rear
cylinder
On the left side of the
frame
Connector CA2
4-pole
6
Control motor for the
2nd throttle
On the throttle body
4
3
2
1
Connector CA
4-pole
4
Rear lambda probe
On the left next to the
battery case
Connector CA1
4-pole
5
Front lambda probe
On the right side of the
frame
5
1
2
3
4
6
