OPERATING ELEMENTS 11
4.11Speedometer activation and test
400313-01
Activating the speedometer:
The speedometer is activated when one of the keys is pressed or an impulse comes
from the wheel speed sensor.
Display test
For the function test of the display, all display segments light up briefly.
400314-01
WS (wheel size)
After the function test of the display, the wheel size WS is displayed.
Info
2205 mm corresponds to the size of the 21" front wheel with a series produc-
tion tire.
The display then changes to the last selected mode.
4.12Tripmaster switch
(Option: Tripmaster switch)
You can use the trip master switch to control the functions of the speedometer from the handlebar.
Info
The trip master is an optional accessory.
4.13Setting kilometers or miles
Info
If you change the unit, the ODO value is retained and converted accordingly.
The values TR1, TR2, A1, A2 and S1 are deleted at the changeover.
Condition
The motorcycle is standing.
400329-01
– Press the button briefly and repeatedly until H appears at the bottom right of the
display.
– Press the button for 3 - 5 seconds.
The Setup menu opens and the active functions are displayed.
– Press the button repeatedly until the Km/h / Mphdisplay flashes.
Setting Km/h
– Press the button "+".
Setting Mph
– Press the button "‑".
– Press the button for 3 - 5 seconds.
The settings are saved and the Setup menu closed.
Info
If no button is pressed for 20 seconds, or if no impulse comes from the
wheel speed sensor, the settings are automatically saved and the Setup
menu closed.
