TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 84

18TECHNICAL DATA- CHASSIS TIGHTENINGTO RQUES

Remaining screws, chassis M5 4 Nm (2.95 lbf ft) –

Screw, fuel tap on frame M5 5 Nm (3.69 lbf ft) –

Screw, brake line on bottom triple

clamp

M5 2 Nm (1.48 lbf ft) –

Screw, foot brake pedal surface M5 6 Nm (4.43 lbf ft)

Loctite

243™

Spoke nipple, rear wheel M5 5 Nm (3.69 lbf ft) –

Spoke nipple, front wheel M5 5 Nm (3.69 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.38 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.38 lbf ft) –

Screw, compensating tank of rear

brake

M6 5 Nm (3.69 lbf ft) –

Screw, battery holder on rear tank M6 3 Nm (2.21 lbf ft) –

Screw, rear brake disc M6 14 Nm (10.33 lbf ft)

Loctite

243™

Screw, front brake disc M6 14 Nm (10.33 lbf ft)

Loctite

243™

Screw, shock absorber adjusting ring M6 5 Nm (3.69 lbf ft) –

Screw, spring retainer for side stand M6 10 Nm (7.38 lbf ft)

Loctite

243™

Screw, rear foot brake cylinder M6 10 Nm (7.38 lbf ft)

Loctite

243™

Screw, bottom radiator bracket M6 5 Nm (3.69 lbf ft) –

Screw, regulator-rectifier M6 8 Nm (5.9 lbf ft)

Loctite

243™

Screw, starter cable on starter M6 10 Nm (7.38 lbf ft) –

Screw, motor guard M8 25 Nm (18.44 lbf ft) –

Engine carrying screw M8 30 Nm (22.13 lbf ft)

Loctite

243™

Nut, rear sprocket screw M8 35 Nm (25.82 lbf ft)

Loctite

243™

Remaining nuts, chassis M8 25 Nm (18.44 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.44 lbf ft) –

Screw, front brake caliper M8 30 Nm (22.13 lbf ft)

Loctite

243™

Screw, foot brake pedal M8 25 Nm (18.44 lbf ft)

Loctite

243™

Screw, top triple clamp M8 17 Nm (12.54 lbf ft) –

Screw, bottom triple clamp M8 12 Nm (8.85 lbf ft) –

Screw, fork stub M8 15 Nm (11.06 lbf ft) –

Screw, steer tube M8 25 Nm (18.44 lbf ft)

Loctite

243™

Screw, top steering stem M8 20 Nm (14.75 lbf ft) –

Screw, rear tank fixing bracket M8 20 Nm (14.75 lbf ft)

Loctite

243™

Screw, handlebar clamp M8 16 Nm (11.8 lbf ft) –

Screw, side stand bracket M8 25 Nm (18.44 lbf ft)

Loctite

243™

Screw, beam, engine support bracket M8 25 Nm (18.44 lbf ft)

Loctite

243™

Screw, reinforcement plate on rear

tank, right and left

M8 25 Nm (18.44 lbf ft) –

Screw, tension strut bearing M8 25 Nm (18.44 lbf ft)

Loctite

243™

Remaining nuts, chassis M10 45 Nm (33.19 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.19 lbf ft) –

Screw, top shock absorber M10 45 Nm (33.19 lbf ft)

Loctite

243™

Screw, bottom shock absorber M10 45 Nm (33.19 lbf ft)

Loctite

243™

Screw, handlebar support M10 40 Nm (29.5 lbf ft)

Loctite

243™

Screw, side stand M10 35 Nm (25.82 lbf ft)

Loctite

243™

Nut, triangular lever arm M14x1.5 100 Nm (73.76 lbf ft) –

Nut, swingarm pivot M14x1.5 100 Nm (73.76 lbf ft) –

Screw, top steering head M20x1.5 12 Nm (8.85 lbf ft) –

Screw, front wheel spindle M24x1.5 40 Nm (29.5 lbf ft) –

Nut, rear wheel spindle M25x1.5 90 Nm (66.38 lbf ft) –
