TECHNICAL DATA - CHASSIS 80
15TECHNICAL DATA- CHASSIS
Frame Trellis frame of chromium-molybdenum steel tubes, powder-
coated
Suspension travel
front 300 mm (11.81 in)
Rear 310 mm (12.2 in)
Fork offset
Mark 1 visible 20 mm (0.79 in)
No mark 22 mm (0.87 in)
Brake system Disc brakes, brake calipers on floating bearings
Diameter of brake discs
front 300 mm (11.81 in)
Rear 240 mm (9.45 in)
Wear limit of brake discs
front 4.5 mm (0.18 in)
Rear 3.5 mm (0.14 in)
Tire air pressure on road
front 1.5 bar (21.76 psi)
Rear 1.5 bar (21.76 psi)
Tire air pressure off road
front 1… 1.5 bar (14.5… 21.76 psi)
Rear 1… 1.5 bar (14.5… 21.76 psi)
Rear wheel gearing 16:44
Rear sprockets available 43, 44, 45
Chain 5/8 x 1/4"
Wheelbase 1535±10 mm (60.43±0.39 in)
Steering head angle 62.5°
Seat height unloaded 980 mm (38.58 in)
Ground clearance unloaded 320 mm (12.6 in)
Weight without fuel 162 kg (357.15 lb.)
Maximum permissible front axle load 190 kg (418.87 lb.)
Maximum permissible rear axle load 250 kg (551.15 lb.)
Maximum permissible overall weight 400 kg (881.84 lb.)
Standard rider weight 75… 85 kg (165.34… 187.39 lb.)
15.1Lighting equipment
High beam P20d 12 V
60 W
Low beam P20d 12 V
60 W
Parking light W2,1x9,5d 12 V
5 W
Indicator lights W2x4,6d 12 V
1.2 W
Flasher light BAU15s 12 V
10 W
Brake / tail light LED
Licence plate lamp W2,1x9,5d 12 V
5 W
Battery YTZ10S 12 V
8.6 Ah
maintenance-free
