MAINTENANCE WORK ON CHASSIS AND ENGINE 50
Info
KTM recommends DOT 5.1 brake fluid from Motorex
®
. This has a higher wet boiling point than DOT 4 brake fluid and provides
greater safety for high demands.
Never user DOT 5 brake fluid! This is based on silicone oil and is colored purple. Oil seals and brake lines are not designed for
DOT 5 brake fluid.
Avoid contact between brake fluid and painted parts. Brake fluid attacks paint!
Use only clean brake fluid from a sealed container!
600061-10
– Remove the rear brake linings. ( P. 48)
– Stand the vehicle upright.
– Turn the brake fluid cap in the direction of the arrow and remove it with mem-
brane .
– Press the brake piston back to its basic position and make sure that no brake fluid
overflows from the reservoir.
– Mount the rear brake linings. ( P. 49)
– Top up the brake fluid to level .
Brake fluid DOT 5.1 ( P. 96)
– Check parts for damage and wear. Replace damaged or worn parts.
– Insert the membrane into the brake fluid reservoir and mount the brake fluid
cap .
– Clean up overflowed or spilt brake fluid immediately with water.
8.52Removing front wheel x
– Jack up the motorcycle. ( P. 29)
600031-10
– Press the brake caliper by hand on to the brake disc in order to press back the
brake pistons.
Info
Make sure when pushing back the brake pistons that you do not press the
brake caliper against the spokes.
600032-10
– Loosen screw .
– Remove screw .
– Loosen screw .
– Holding the front wheel, withdraw the wheel spindle. Take the front wheel out of
the fork.
Info
Do not pull the hand brake lever when the front wheel is removed.
Always lay the wheel down in such a way that the brake disc is not dam-
aged.
600033-10
– Remove the distance bushing .
