MAINTENANCE WORK ON FRAME AND ENGINE 120
9.49Changing the ABS fuses (990 Adventure)
Warning
Fire hazard The electrical system can be overloaded by the use of incorrect fuses.
– Use only fuses with the prescribed amperage. Never by-pass or repair fuses.
Info
Two fuses for the ABS are located under the right underride guard. These fuses protect the return pump and the hydraulic unit of
the ABS. The third fuse, which protects the ABS control unit, is located in the fuse box.
– Switch off all power consumers and the engine.
– Remove the right underride guard. ( p. 117)
100585-10
Changing the fuse of the ABS hydraulic unit:
– Remove protective cover and remove fuse .
Info
A spare fuse is located next to the fuse box in the storage compartment.
– Install the new fuse.
Fuse (58011109125) ( p. 189)
– Check whether the ABS warning lamp is still lit.
– Mount the protective cover.
Tip
Place the spare fuse in the storage compartment so that it is available if
needed.
