MAINTENANCE WORK ON FRAME AND ENGINE 161
9.83Installing the oil filter x
100631-10
– Insert oil filter .
– Lubricate the O-ring of the oil filter cover. Install oil filter cover .
– Mount and tighten the screws.
Guideline
Remaining engine screws M5 6 Nm (4.4 lbf ft)
9.84Filling up with engine oil x
Info
Too little engine oil or poor-quality engine oil results in premature wear to the engine.
100622-10
– The oil must be added in two steps.
Engine oil 3.0 l (3.2 qt.) External
temperature:
≥ 0 °C (≥ 32 °F)
Engine oil
(SAE 10W/50)
( p. 202)
External
temperature:
< 0 °C (< 32 °F)
Engine oil (SAE
5W/40) ( p. 202)
– Remove the dipstick and add engine oil.
Engine oil (1st
quantity) approx.
2.50 l (2.64 qt.) External
temperature:
≥ 0 °C (≥ 32 °F)
Engine oil
(SAE 10W/50)
( p. 202)
