MAINTENANCE WORK ON FRAME AND ENGINE 127
– Remove the headlight mask with the headlight. ( p. 125)
100594-10
– Remove rubber cap and disconnect plug-in connector .
100595-10
– Detach spring bar and remove the bulb from the headlight.
– Position the new bulb in the headlight and attach the spring bar.
High beam (H3 / socket PK22s) ( p. 190)
Info
The bulb must be correctly seated at projections .
– Connect the plug-in connector and mount the rubber cap.
– Install the headlight mask with the headlight. ( p. 126)
9.56Changing the low beam bulb
Note
Damage to reflector Reduced luminance.
– Grease on the lamp will evaporate due to the heat and be deposited on the reflector. Clean the lamp and keep it free of grease before
mounting.
