MAINTENANCE WORK ON FRAME AND ENGINE 159
100625-10
– Position the bracket . Mount and tighten screws .
Guideline
Remaining chassis screws M8 25 Nm
(18.4 lbf ft)
– Mount and tighten screw on the right fuel tank.
Guideline
Screw, fuel tank M8 15 Nm
(11.1 lbf ft)
9.82Removing the oil filter x
Warning
Danger of scalding Engine oil and gear oil get very hot when the motorcycle is ridden.
– Wear appropriate protective clothing and safety gloves. In case of burns, rinse immediately with lukewarm water.
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations.
Condition
The underride guard has been removed.
– Place a suitable container under the engine.
