CONTROLS 19

5.1Clutch lever

100505-10

The clutch lever  is fitted on the left side of the handlebar.

The clutch is hydraulically operated and self-adjusting.

5.2Hand brake lever

100506-10

The hand brake lever  is fitted on the right side of the handlebar.

The front brake is engaged using the hand brake lever.
